MCX to FAKRA RF Test Probe

MCX to FAKRA RF Test Probe for Automotive RF Validation

Adapter Series 1 & 2: MCX to FAKRA
Adapter Gender: Female to Plug
Body Materials and Plating: Copper Alloy Gold Plated
Frequency Range (From DC): 2GHz
Impedance: 50 Ohm
Voltage Rating: 335 V(rms)
Dielectric Withstanding Voltage: >100 V
Insulation Resistance: ≥500 Mohm
Probe Durability: ≥ 20000 cycles
Mating Cycles: MCX side ≥ 500 cycles
Operating Temperature: -45°C ~ +80°C
Mating Torque: 5~7 in – lbs
Compliance & Standards: RoHS Compliant, MIL-STD-202
MOQ & Customization: 1 Piece

CAD data

PDF Download

MCX to FAKRA RF Test Probe: Precision Tools for Modern RF Validation

Our MCX to FAKRA RF Test Probes are engineered to provide a critical interconnect solution between test equipment and devices under test (DUTs) in modern automotive and telecommunications systems. These probes feature a robust MCX Female connector on one end and a secure FAKRA Plug interface on the other, operating reliably across a frequency range of DC to 2GHz with a consistent 50 Ohm impedance. Crafted from high-grade materials, they are built to withstand the rigors of both R&D and production environments, ensuring accurate signal transmission and long-term durability for demanding validation workflows.

Core Applications: Where Our RF Test Probes Excel

The primary application of our MCX to FAKRA RF Test Probe is in the automotive industry, where they are indispensable for validating key systems. They are perfectly suited for testing GPS modules, vehicle antenna systems, and telematics control units. Beyond automotive, these probes are also widely used in general-purpose RF testing, IoT device validation, and any scenario requiring a stable and reliable connection between MCX-based instrumentation and a FAKRA-compliant DUT. Their design ensures minimal signal loss and reflection, making them ideal for precision measurements.

Our Unbeatable Advantages: Flexibility, Quality, and Global Support

We differentiate ourselves by offering unparalleled flexibility and commitment to our clients’ unique needs. Unlike many suppliers who enforce high minimum order quantities, our foremost advantage is that the minimum order quantity (MOQ) is just 1 piece. This policy applies universally, meaning for custom products, the starting quantity is also 1 piece, and we accept orders globally. Whether you need a single prototype or a full production run, you can access our top-tier quality and custom engineering services. We empower your innovation by removing volume barriers, allowing you to test, iterate, and scale on your own terms. Coupled with our competitive pricing and direct engineering support, we provide a risk-free pathway to the perfect MCX to FAKRA RF Test Probe solution for your project.

Production Process

Product Detail Sheet

Category	Parameter	Description
Product Information	Product Name	MCX to FAKRA RF Test Probe
	Brand	REECUFUTURE
	Minimum Order Quantity	1 Piece
	Packaging	Boxed
	Origin	Shanghai, China
Configuration	Adapter Series 1	MCX
	Adapter Gender 1	Female
	Adapter Angle 1	Straight
	Adapter Mount Method 1	None
	Body Materials and Plating 1	Copper Alloy Gold Plated
	Adapter Series 2	Fakra
	Adapter Gender 2	Plug
	Adapter Angle 2	Straight
	Adapter Mount Method 2	None
	Body Materials and Plating 2	Copper Alloy Gold Plated
Electric Specifications	Impedance	50ohm
	Frequency Range (From DC)	2GHz
	VSWR	TBD
	Insertion Loss	TBD
	Voltage Rating	335 V(rms)
	Dielectric Withstanding Voltage	>100 V
	Insulation Resistance	≥500 Mohm
Mechanical Characteristics	Mating Cycles	MCX side ≥ 500 cycles
	Probe Durability	≥ 20000 cycles
	Mating Torque	5~7 in – lbs
Environmental Characteristics (RoHS Compliant)	Temperature Rating	-45°C ~ +80°C
	Corrosion (Salt Spray)	MIL-STD-202, Method 101, Condition B
	Vibration	MIL-STD-202, Method 204, Condition D, 20 Gs
	Shock	MIL-STD-202, Method 213, Condition I, 100 Gs
	Thermal Shock	MIL-STD-202, Method 107. Cond. B, -40°C to +85°C
	Moisture Resistance	MIL-STD-202, Method 106, Less Step 7B
	Barometric Pressure (Altitude)	MIL-STD-202, Method 105, Condition C, 70k Ft.

Packaging & Shipping

📦 Precision ESD-Safe Packaging
Every RF component—from connectors and probes to cable assemblies—is secured with multi-layer, ESD-compliant packaging. We use static-shielding bags, custom-fit foam inserts, and reinforced boxes to prevent physical shock, moisture, and electrostatic discharge during transit, ensuring product integrity upon arrival.

✈️ Global Logistics & Express Shipping
We partner with leading global express carriers like DHL, FedEx, and UPS, alongside air and ocean freight specialists. We tailor shipping solutions from China to worldwide destinations, supporting everything from sample parcels to bulk orders under EXW, FOB, or CIF terms. Our service includes full documentation, customs brokerage, and real-time tracking for seamless door-to-door delivery.

🕒 Reliable & On-Time Delivery
Leveraging seasoned logistics coordination and reliable carrier relationships, we guarantee timely and accurate fulfillment. Whether you're ordering R&D samples or production volumes, we ensure swift processing and punctual shipping—so you can stay on schedule and focused on innovation.

Industry Applications

🔧 Core Technology Sectors
Our precision RF components serve mission-critical applications across 8 key sectors: 5G communications, automotive electronics, aerospace/defense, semiconductor testing, IoT, medical electronics, satellite communications, and industrial automation. Each domain relies on our solutions for uncompromised signal integrity.

🛠 Tailored Performance Solutions
We develop specialized configurations for unique industry requirements – from phase-stable cable assemblies for radar systems to micro-pitch probes for chipset validation. Our engineering team translates technical specifications into reliable performance under demanding operating conditions.

💡 Cross-Industry Innovation Synergy
By serving diverse sectors, we accumulate unique insights that drive innovation. Technologies developed for aerospace often benefit automotive applications, creating continuous improvement cycles that deliver superior value to all partners.

FAQ

1. What is your minimum order quantity for MCX to FAKRA RF Test Probe?
We proudly offer custom manufacturing with a 1-piece MOQ and accept orders globally for all our MCX to FAKRA RF test probes, serving both automotive prototyping and production needs.

2. What automotive applications are your MCX to FAKRA RF Test Probe designed for?
Our MCX to FAKRA RF test probes are specifically engineered for vehicle antenna systems, GPS modules, and infotainment system validation in automotive manufacturing environments.

3. What’s the frequency range of your MCX to FAKRA RF Test Probe?
These automotive MCX to FAKRA RF test probe support frequencies from DC to 2GHz, covering most vehicle communication and navigation system requirements.

4. What connector types does your MCX to FAKRA RF Test Probes feature?
The MCX to FAKRA RF test probe feature an MCX Female connector on one end and a standard Fakra Plug on the other, specifically designed for automotive testing applications.

5. How durable are your MCX to FAKRA RF Test Probe for production line use?
Our MCX to FAKRA RF test probe are built with high-cycle life durability to withstand the demands of automotive production testing environments.

6. What materials are used in your MCX to FAKRA RF Test Probes construction?
We use copper alloy with gold plating in our MCX to FAKRA RF test probes to ensure optimal signal integrity in automotive applications.

7. Are your MCX to FAKRA RF Test Probes suitable for automotive antenna testing?
Absolutely. With its 2GHz bandwidth and Fakra interface, our MCX to FAKRA RF test probe are perfectly suited for vehicle antenna system validation and production testing.

8. What quality standards do your MCX to FAKRA RF Test Probe meet?
All our MCX to FAKRA RF test probe are manufactured to meet automotive testing requirements and quality standards.

9. Do you provide technical support for custom MCX to FAKRA RF Test Probes configurations?
Yes, we offer comprehensive engineering support for both standard and custom MCX to FAKRA RF test probe applications, all starting from our 1-piece MOQ policy.

10. What’s the delivery time for custom MCX to FAKRA RF Test Probes orders?
Standard MCX to FAKRA RF test probe configurations ship within 3-5 days, while custom designs typically deliver within 1-2 weeks, even for single-piece orders.
